>AC vs DC: why does it matter?<

What’s this thing about AC anyway? A little history lesson might be in order. It all started when Edison built the first incandescent bulb and the power station to light it. A big disadvantage of DC electricity immediately revealed itself: you couldn’t build the power houses any further than a few blocks from where the electricity was produced.
Why? The resistance ...of the wire consumed a portionof the power. Houses close to thepower station had brilliant lights andthose at the furthermost reach had dimones. The last guy on the line had it bad. When someone close to the powerhouse turned on a whole bunch of lights, his woulddim even further. And pity the poor farmer! He couldn’t get any power out there in the country until a few companies got smart and started manufacturing wind-electric machines.
Then along came Nikola Tesla, thefather of AC motors and generators. Ifyou make AC at any voltage, it can be transformed through use of the highly efficient transformer to any other voltage. Stepping up the voltage has the effect of stepping down the current for the same power transfer.
Why does DC vs AC matter?
Power delivered to the “load” (anything which uses power) is defined as the productof Amps and Volts, or P=IV. On the other hand, line losses (the energy lost in the transmission wires) are determined by the product of Amps squared times ohms (the resistance of the wire), or P=RI2.
Note that voltage plays no part in line losses.
With AC, then, the transformer stepped up the voltage (or down, depending on the ratio of the number of windings of input and output) to hundreds of thousands of Volts. Naturally, since “power out” must equal “power in” (minus losses), the AC current decreased in the same proportion.
Thus, super-high voltage and super-low current meant very low line losses irrespective of how far you needed to send it. Of course, very high voltage is dangerous stuff for appliances, lights, and motors.
With AC, however, once you get the power to the home, farm, or shop, a second transformer (on the utility pole) would step the voltage back down for use.
The point of this historical review
There’s nothing really “sacrosanct” about 120-volt, 60-cycle AC. It is convenient for theutilities to use because it’s the only way they have to transfer power over long distances. If your power is homegrown, you don’t have their problems, so why necessarily accept their solution?
True, after you’ve considered all the factors,you may decide that high voltage will work best for you in your situation.
